GWR Route: North Warwickshire Line
Bordesley Shed: gwrbg-shed1956
Schematic drawing showing the end elevation of the 1854 broad
gauge Birmingham Engine House at Bordesley. The door on the right appears to
have been provided to facilitate pedestrian access to the shed. Sketched by RS
Potts in 1997 for the Broad Gauge Society's Magazine, the above elevation was
part of a drawing (the other two parts being 'gwrbg-shed1956' and 'gwrbg-shed1959') notes that the original drawing
was prepared in the Engineers Office at Paddington and were signed ER for CS,
dated April 1 1854 and traced at Fluyder Street. RS Potts further records
Public Record Office, Kew, RAIL 252/95.
