LMS Route: Birmingham New Street to Nuneaton

Nuneaton Abbey Street Station: mrna1941a

A post 1873 plan of the marshalling sidings, located at the divergence of the two MR routes, controlled from Abbey Junction Sidings Signal Box

A post 1873 plan of the marshalling sidings, located at the divergence of the two MR routes, controlled from Abbey Junction Sidings Signal Box. When the signalling to the running lines was replaced by colour aspect signals, the Signal Box was down graded as a ground frame. On the extreme right, the MR lines to Leicester can be seen being carried over the quadruple track Trent Valley main line and the MR connection into the LNWR station.
