GWR Route: North Warwickshire Line
Henley in Arden - Original Station: gwrha3878
Detailed plan and elevation of the Station Road Approach
(now Millfield Court / William James Way) bridge over the River Alne in
Henley-in-Arden. The plan is stamped Birmingham and Henley-in-Arden Railway
1893, one year before the branch line opened. The twenty foot span bridge
supported a cambered road twenty foot wide on seven steel joists (23 long
x 16 x 6), at 3 7.5 centres with brickwork arches
between the joists and restraining tie rods at 5 foot intervals. The bridge was
designed for a maximum weight of 12 tons.
A copy of the above document in a large PDF format is
available here.
