GWR Route: Banbury to Wolverhampton

Southam Road and Harbury: gwrsrh290a

Close up showing the  layout of the track to the south of the station with the down refuge siding on the right

Close up of image 'gwrsrh290' showing the layout of the track to the south of the station with the down refuge siding on the right. The four signals seen in image 'gwrsrh280a' have been the subject of change. The signal on the right controlling the down refuge siding remains in the same position although the arm seems to have been changed and in the process lost the circle on the arm. The tall down signal located adjacent to the two up signals on the left has now been replaced by a shorter signal located in the 'six foot'. The two up signals remain as before but have had 'siting boards' placed behind the signal arm to enable drivers to see them against the dark background of the embankment and bridge.
