Tyseley Shed: gwrt2967

GWR Property Map showing the proposed Tyseley Station, Goods Yard infrastructure, Engine Shed, Carriage Shed, Signal boxes and the junction with the North Warwickshire Line

Great Western Railway Property Map showing the proposed Tyseley Station, Goods Yard infrastructure, Engine Shed, Carriage Shed, Signal boxes and the junction with the North Warwickshire Line. It has the legal ownership of the land to be purchased identified. The western side of the site adjacent to the river Cole was low laying and several culverts were required to be constructed. A feeder arm to the Birmingham and Warwick Canal from the Goods Yard was proposed and a large Stables can be seen. On the south side near the station, an area was reserved for the Signal and Telegraph Department. This map was on display at the Birmingham Railway Museum at Tyseley.

Robert Ferris
