LNER Route: Leicester to Marylebone

Rugby Central Station: gcrcs199c

Close up of image 'gcrcs199' showing a detailed plan, a front to rear cross-section and a rear road level section of Rugby station. In the sectional drawing on the right the walkway through to the stairs can be seen. In addition, there is evident that a serving window from the parcels office opening into the walkway. The central drawing shows that the booking office had an ornate wooden frontage facing into the booking hall which had a high vaulted ceiling.
