Birmingham New Street Station: lnwrbns_str1841a

Close up of New Street No 2 Signal Box which protected the 'Midland' portion of New Street station and the timber bracket signals controlling departures to Derby

Close up of image 'lnwrbns_str1841' showing New Street No 2 Signal Box which protected the 'Midland' portion of New Street station and the timber bracket signals controlling departures to Derby. The Signal Box stood at the end of the original Platform 5 (the LNWR named the entire island platform as Platform 5) to be redesignated in 1946 as Platforms 8 for the right hand platform face and Platform 9 for the left hand platform face. Immediately in front of the signal box are the timber buffer stops for a short siding used by pilot locomotives at the station during periods when the through lines were being occupied.
