LMS Route: Evesham to Birmingham

Harvington Station: mrhv1333

Schematic Signalling Diagram showing Harvington station's layout and the lever number associated with each signal. Harvington Signal Box was equipped with a frame accommodating a total of eighteen levers, of which five were spare, standard practice where installing signal boxes in case more levers were needed in the future.
